UL3135 Extra Soft Silicone Flexilis Lithium Pugna Wire 18AWG

UL3135 Extra Soft Silicone Flexilis Lithium Pugna filum (18AWG) ordinatur ad salutem superiorem, flexibilitatem et resistentiam calidi. Certificatum sub UL758 (E301946) et cum RoHS admonitionibus obsecundantem, hoc filum humilis toxicitatem et salutem environmental efficit.

Cum aestimata intentione 600V et temperatura range of -60°C ad CC°C, excellit in ambitibus exigendis. conductor aeris nudo, cupro tincto, argenteo patella, vel nickel-patella efficitur aeris, ut praestans electricae conductionis et diuturnitatis. Silicone rubber insulatio eius flexibilitatem eximiam praebet, institutionem sine labore faciens, etiam in spatiis strictis.

Praesto magnitudinum ab 26AWG ad 16AWG (0.128mm²~1.31mm²), hoc filum specimen est pro filo internis machinarum electronicarum, lithium sarcinarum altilium, et alias applicationes altae temperaturas. Utrum usus sit in machinationibus industrialibus, roboticis, vel electronicis potentia, UL3135 est summa electio professionalium quaerendorum certa et diuturna observantia in extremis conditionibus..

Contact Us
PREV：UL3530 High Temperature Repugnans Silicone Mollis instruitur LineaDEINDE：Proximum productum non
Parameter
AWG
NO. 		Spec.
mm²） 		Conductor Insulation Diameter filum Max
resistentia
20℃(Ω/KM)
Structure
mm） 		Diameter
mm） 		Nominal
crassitudine
mm） 		Min
crassitudine
mm） 		Nominal
mm） 		tolerantia
mm）
26 0.128 7/0.168/0.15 0.48 0.76 0.69 2 ±0.10 150
24 0.205 7/0.20 0.6 0.76 0.69 2.15 ±0.10 94.2
22 0.324 7/0.25413/0.18 0.75 0.76 0.69 2.3 ±0.15 59.4
20 0.519 7/0.3221/0.18 0.96 0.76 0.69 2.5 ±0.15 36.7
18 0.823 7/0.3933/0.18 1.2 0.76 0.69 2.75 ±0.20 23.2
16 1.31 7/0.4952/0.18 1.47 0.76 0.69 3 ±0.20 14.6
14 2.08 64/0.20 1.9 0.76 0.69 3.45 ±0.25 8.96
7/0.6241/0.254
12 3.31 19/0.4942/0.32 2.5 0.76 0.69 4.05 ±0.25 5.64
26 0.128 1/0.42 0.42 0.76 0.69 1.95 ±0.10 143
24 0.205 1/0.50 0.52 0.76 0.69 2.05 ±0.10 89.3
22 0.324 1/0.62 0.65 0.76 0.69 2.2 ±0.15 56.4
20 0.519 1/0.80 0.82 0.76 0.69 2.35 ±0.15 35.2
18 0.823 1/1.00 1.05 0.76 0.69 2.6 ±0.20 22.2
16 1.31 1/1.30 1.3 0.76 0.69 2.85 ±0.20 140
Quaeso contactus elit ut providere productum determinationes.
